Sinotruk Howo 6×6 All-Wheel-Drive Off-Road Mining Dump Truck

1 / 5

Sinotruk Howo 6×6 All-Wheel-Drive Off-Road Mining Dump Truck

The Sinotruk Howo 6x6 All-Wheel-Drive Off-Road Mining Dump Truck is a heavy-duty tipper specifically engineered for the most demanding mining and construction environments. Built on Sinotruk's proven and mature core assembly technologies, this all-wheel-drive workhorse delivers exceptional reliability, powerful performance, and superior off-road capability. The 6x6 configuration provides greater power and improved escape capability compared to conventional 6x4 configurations, making it the ideal choice for transporting minerals, ore, sand, and gravel in harsh mining conditions. Whether navigating muddy country roads, rugged mountain terrain, or steep inclines, the Howo 6x6 dump truck ensures stable and efficient operation under the most challenging conditions.

Send Inquiry

Product Description

Core Specifications

Item	Specification
Drive	6×6 all‑wheel drive
Engine	WD615 / WD10 / WP12, 336–400 HP, Euro II
Transmission	HW19710, 10F + 2R, with PTO
Rear Axle	ST16 tandem, 32,000 kg capacity, ratio 5.73
Frame	U‑profile, 300×80×8 mm, high‑strength steel
Tires	12.00R20 (10+1 spare)
Cargo Body	5.4–5.8 × 2.3 × 1.45–1.5 m, floor 8 mm / side 6 mm wear‑resistant plate
Wheelbase	3,625 + 1,350 mm
Overall Size (L×W×H)	~8,750 × 2,550 × 3,450 mm
Fuel Tank	300 L
Brake System	Dual‑circuit air brake + spring parking brake + exhaust brake

Key Advantages

6×6 All‑Wheel Drive

Superior grip and escape capability on loose or slippery surfaces.

Powerful Engine

Up to 400 HP with high torque for heavy climbing and loaded starts.

Heavy‑Duty Axles

Rear tandem load up to 32,000 kg, with wheel‑side reduction for extra torque.

Reinforced Chassis & Body

High‑strength frame and wear‑resistant cargo box withstand harsh mining impacts.

Driver‑Friendly Cabin

Suspension seat, A/C, and shock‑absorbed mounting reduce fatigue on long shifts.

Frequently Asked Questions

What are the engine options and horsepower ratings for this vehicle?

The vehicle can be equipped with WD615, WD10, or WP12 Euro II engines, delivering a power output ranging from 336 to 400 HP to provide optimal torque and heavy climbing capability.

How does the 6×6 all-wheel drive benefit off-road operations?

The 6×6 all-wheel drive system distributes power to all wheels, ensuring superior traction, stability, and excellent escape capabilities when operating on loose, muddy, or slippery terrains.

What is the load capacity of the rear tandem axle?

The rear tandem axle is a heavy-duty ST16 model with a load capacity of up to 32,000 kg. It features wheel-side reduction to output extra torque under demanding loads.

What materials and dimensions are used for the cargo body?

The cargo body measures 5.4–5.8m in length, 2.3m in width, and 1.45–1.5m in height. It is constructed with wear-resistant plates featuring an 8 mm thick floor and 6 mm thick sides to withstand heavy impact.

What features ensure driver comfort during long work shifts?

The cabin is designed to minimize operator fatigue by incorporating a comfortable suspension seat, air conditioning (A/C), and shock-absorbed cabin mountings for a smoother ride.

What type of brake system does this truck utilize?

For safety, the vehicle is equipped with a dual-circuit air brake system, a spring parking brake for secure stationary holds, and an exhaust brake to assist during downhill descents.
