| Model | GL3004 | GL3005 | GL3305 |
|---|---|---|---|
| Max Lifting Capacity (kg) | 12,000 | 12,000 | 13,000 |
| Max Lifting Moment (kN·m) | 300 | 300 | 330 |
| Max Working Arm Length (m) | 15.5 | 17.3 | 17.3 |
| Max Working Height (m) | 16.5 | 18.5 | 18.5 |
| Boom Elevation Range (°) | 0–75 | 0–75 | 0–75 |
| Swivel Angle (°) | 360 | 360 | 360 |
| Outrigger Span (m) | 5.95 | 5.95 | 7.1 |
| Rated Working Flow Rate (L/min) | 50+40 | 50+40 | 50+40 |
| Weight (kg) | 4,700 | 4,900 | 5,300 |
Maximum lifting capacity up to 13,000 kg, suitable for heavy-duty lifting and material handling.
Max working arm length up to 17.3m and working height up to 18.5m, ideal for construction sites, loading docks, and infrastructure projects.
Continuous rotation allows precise positioning without moving the truck.
Up to 7.1m outrigger span provides excellent stability during lifting operations.
Rated working flow rate of 50+40 L/min ensures smooth and responsive boom control.
GL3004, GL3005, and GL3305 available to match different lifting needs and budget requirements.
Heavy-duty 8×4 configuration delivers superior load-bearing capacity and stability for crane mounting.
Robust design with weight ranging from 4,700–5,300 kg ensures long-term reliability in demanding environments.
Yes, we have our own factory, our own engineers and we can meet the unique requirements of our customers.
American and German trailer axles, trailer mechanical suspensions, air suspensions, bogie suspensions, trailer parts including leaf springs, air chambers and more. We also offer affordable used trucks and dump trucks.
Generally, we pack in fumigation-treated wooden crates. If you have legally registered patents, we can pack the goods in your branded crates after obtaining your authorisation letter.
T/T 30% as deposit and pay the balance (70%) against BL copy. We will show you photos of the product and the parcel before you pay the balance.
EXW, FOB, CFR, CIF, DDU.
Yes, we have 100% test before delivery.
