FAW Jiefang 30 Tons 6×4 Heavy Duty Dump Truck for Mining

1 / 5

FAW Jiefang 30 Tons 6×4 Heavy Duty Dump Truck for Mining

The FAW Jiefang 30-Ton 6×4 Heavy Duty Dump Truck is a rugged mining workhorse built on the J6P or JH6 platform. Designed for open-pit mining, quarrying, and earthmoving, this 6×4 (10-wheel) tipper features a reinforced chassis, high-torque diesel engine, and heavy-duty hydraulic dumping system for efficient transport of ore, coal, and gravel.

Send Inquiry

Product Description

Specifications & Parameters

Parameter	Details
Brand	FAW Jiefang
Model	J6P / JH6 6×4 Dump Truck
Condition	Used
Drive Type	6×4 (10 wheels)
Fuel Type	Diesel
Horsepower	350 – 500 HP
Emission Standard	Euro 2 – Euro 6
Engine Brand	FAW Xichai / Weichai
Engine Capacity	8.6 – 11 L
Cylinders	6
Maximum Torque	1500 – 2300 Nm
Transmission	Manual (FAST 9/10/12-speed)
GVW	25,000 – 60,000 kg
Payload	30 tons
Cargo Body Dimensions	4800-6000 × 2300-2500 × 1500 mm
Fuel Tank Capacity	400 – 500 L
Tire Number	10
Tire Size	12.00R20
Front Axle	7 – 9 tons
Rear Axle (Tandem)	16T + 16T
Suspension	Leaf spring
Brake System	Air brake, ABS, engine brake
Max Gradeability	70%
Max Speed	75 – 85 km/h
Steering	Left (Right available)
Cab Type	Spacious sleeper cab with air seat & AC
Dump Mechanism	Hydraulic front lift

Key Advantages

1. High Payload

Rated for 30 tons, with GVW up to 60 tons – maximizes efficiency per trip.

2. Powerful Engine

FAW Xichai or Weichai engine, 350–500 HP, with high torque for steep climbs.

3. Strong 6×4 Drive

10 wheels with tandem rear axles for excellent traction on rough, muddy terrain.

4. Heavy-Duty Dump Body

Wear-resistant steel cargo bed with hydraulic front lift for fast, safe unloading.

5. Off-Road Ready

High ground clearance, 12.00R20 tires, and differential locks for steep slopes.

6. Durable Build

Reinforced frame and robust axles for long life in harsh mining conditions.

7. Driver Comfort & Safety

Spacious cab with air suspension seat, AC, ABS, and engine brake.

8. Global Support

Worldwide service network with video support and online diagnostics.

Frequently Asked Questions

Q1: What is the load capacity of this used FAW Jiefang dump truck?

The dump truck is designed for heavy-duty hauling, offering a rated payload of 30 tons and a Gross Vehicle Weight (GVW) configuration between 25,000 kg and 60,000 kg.

Q2: What engine brands and horsepower range are available?

These trucks are equipped with high-performance FAW Xichai or Weichai diesel engines, ranging from 350 to 500 horsepower to ensure sufficient power for tough terrains.

Q3: Can the truck handle steep slopes and off-road mining routes?

Yes. With a powerful 6×4 drive system, 10 rugged 12.00R20 tires, leaf spring suspension, and a maximum gradeability of up to 70%, this dump truck is fully capable of navigating tough off-road environments and steep mining slopes.

Q4: What type of transmission does the vehicle use?

It features a reliable FAST manual transmission system with options for 9, 10, or 12 speeds, allowing drivers optimal control depending on the payload and road conditions.

Q5: What are the configuration choices for steering and driving comfort?

The standard setup is Left-Hand Drive (LHD), though Right-Hand Drive (RHD) versions are available. The cabin is built for long shifts, equipped with a spacious sleeper compartment, air-suspension seats, and full air conditioning.

Q6: How is the unloading mechanism powered?

The dump truck utilizes a heavy-duty hydraulic front lift mechanism combined with a wear-resistant steel cargo bed for quick, stable, and safe material discharge.
